Creating a dynamic React component

Background

In 2016, I was working with a friend on a rock climbing application called Sendero, where you could create routes, projects, and be connected to your friends. For this project, I wanted to use React. As I worked through the application, I realized that there was an opportunity to create an abstract base class for our components.

We have several RESTful resources that could use just single, generic React component to display them. To populate a table dynamically, we need to give some meta-data to the React component. This will take the form of a reusable Ruby JSON-serializer.

React with Rails

Feel free to skip this, as it’s more background.

Because of the react-rails gem, we were using the react_component method in the HTML template to render React to the DOM:

# app/views/projects/index.html.erb

<%= react_component "ProjectList", url: "/projects", pollInterval: 5000, data: @projects.to_json %>

Replaced ProjectList with a GenericResourceList

The GenericResourceList React component takes a collection of a resource from a JSON API.

// app/assets/javascripts/components/_generic_resource_list.js.jsx

var GenericResourceList = React.createClass({

  getInitialState: function() {
    return {
      resources: [],
      attributes: this.props.data
    };
  },

// ...

  loadResourceFromServer: function() {
    $.ajax({
      // ...
    });
  },

  render: function() {
    // ...
  }
});

Note that no resources are given to the component; it fetches those from the server. Instead what’s given are attributes about the resources it expects to receive, so it can create itss table correctly. Column names vary by resource and it’s necessary to have a modular way of supplying them to the React component. Since the React component is still being rendered in Ruby, I wrote a generic serializer (from the ActiveModel::Serializer project) which provides an interface for that information.

The serializer can serialize a Ruby object into JSON and export meta-data about the JSON. This meta-data includes data types of the resource’s attributes.

# app/serializers/partial_project_serializer.rb

class PartialProjectSerializer < GenericSerializer

  class << self
    def json_manifest
      super
    end

    def original_attributes
      [:id, :status, :user, :route, :grade]
    end

    def addons
      {
        "user" => "string",
        "route" => "string",
        "grade" => "string"
      }
    end
  end

  # ...

  def grade
    object.grade.name
  end
end

The internal API of the class is now a little different, but the gist is you just give extra data type information about attributes which cannot be gleamed fromm the database. This is if you’re pulling data off an association and/or renaming attributes in the generated JSON.

The last method, grade is an example of including data not stored in the resource’s database table.

Data is pulled from the database and converted to JSON data types

Here is a Ruby utility class to present data types of the resource for javascript consumption.

# app/models/json_manifest.rb

class JSONManifest

  class << self
    DEREFERENCE_TABLE = {
      "integer" => "number",
      "number" => "number",
      "character varying" => "string",
      "timestamp without time zone" => "string",
      "text" => "string",
      "string" => "string"
    }

    def produce(klass, *attributes)
      dereference(attribute_types(klass).slice(*attributes))
    end

    private

    def attribute_types(klass)
      attributes = klass.columns_hash.map(&:first)
      types = klass.columns_hash.map(&:last).map(&:sql_type)
      HashWithIndifferentAccess[attributes.zip(types)]
    end

    def dereference(attribute_types)
      attribute_types.inject({}) do |collector, (attr, type)|
        collector[attr] = DEREFERENCE_TABLE[type]
        collector
      end
    end
  end

end

Basically, you call JSONManifest.produce with the class to hit the database with and the attributes it cares about. The serializer is still responsible for tacking on any additional attributes in the JSON response because that logic belongs in the presentation layer.

Back to React

The GenericResourceList component is now being rendered like so:

# app/views/projects/index.html.erb

<%= react_component "GenericResourceList", url: "/projects", pollInterval: 5000, data: PartialProjectSerializer.json_manifest %>

The GenericResourceList component

The full code for the GenericResourceList component can be viewed here but the relevant part to using that meta-data in the front end is:

// app/assets/javascripts/components/_generic_resource_list.js.jsx

var GenericResourceList = React.createClass({

  getInitialState: function() {
    return {
      resources: [],
      attributes: this.props.data
    };
  },

  // ...

  render: function() {

    var that = this;

    var genericResourceListItems = this.state.resources.map(function(resource) {
      return (
        <GenericResourceListItem attributes={that.state} resource={resource} />
      );
    });

    var genericResourceListHeaders = Object.keys(this.state.attributes).map(function(attribute) {
      return (
        <th>{attribute}</th>
      );
    });

    return (
      <div className="genericResourceList">
        <table className="genericResourceListTable">
          <tbody>
            <tr>
              {genericResourceListHeaders}
            </tr>
            {genericResourceListItems}
          </tbody>
        </table>
      </div>
    );
  }
});

The eventual DOM structure is:

<table>
  <tbody>
    <tr>
      <th>Name</th>
      <th>Age</th>
    <tr>
    <tr>
      <td knownType="string">Joe Smith</td>
      <td knownType="string">22</td>
    </tr>
  </tbody>
</table>

The knownType attribute is what’s given to React from the Ruby code. I’m not sure exactly how it’s useful at the moment, but it may be in the future.

Conclusion

I believe this is useful for tables displaying a list of resources that:

a) are ActiveRecord-based, and b) contain non-nested data

The latter can be improved with adding “object” to JSONManifest in Ruby and more complex methods in the related serializer.

For reference below is the GenericSerializer which keeps the interface of individual serializers neat.

class GenericSerializer < ActiveModel::Serializer
  class << self

    def json_manifest
      raise StandardError, "Must provide an ActiveRecord class to this method" if resource_class.nil?
      raise StandardError, "Cannot call this method on the superclass" if self == GenericSerializer
      JSONManifest.produce(resource_class, *original_attributes).merge(addons)
    end

    def original_attributes
      if self != GenericSerializer
        raise StandardError, "You must implement #{__method__} on #{self}, with all attributes to serialize. E.g., [:id, :name]"
      end
    end

    # Tack on additional values not stored in this resource's DB table
    # Order must match up with `attributes` method :-\
    def addons
      if self != GenericSerializer
        raise StandardError, "You must implement #{__method__} on #{self}, with all attributes not on #{self}'s table, in order.  See #{__FILE__} for documentation."
      end
    end

    private

    def resource_class
      resource_class_name = /Partial(\w+)Serializer/.match(self.to_s)[1] # this needs improvement
      Object.const_get(resource_class_name)
    rescue NameError => e
      puts e.message
      puts e.backtrace
      raise StandardError, "Could not properly infer resource class name from the serializer's class.  Please rename this class accordingly."
    end
  end

  attributes *self.attributes
end

The code above has several areas for improvements, but for now it is supported by a robust set of tests for GenericSerializer, PartialProjectSerializer, and JSONFormatter.

Thanks for reading!
